LTF-A815AB-2L LED Linear Lightbar

Dimensions:Length: 48" x Width: 11.8" x Height 2.35"

  • Specification
  • Dimensions
  • Video
  • Download Instruction Manual
  • Request Quote

LTF-A815AB-2L Emergency car led Linear Lightbar

1. Summary

 This Starway Warning LED lightbar is made of a lot of high brightness LED lights. it has advantage with high brightness and low power waste and long use life etc.. The light bar has good looking shape and stronger against impulse capability, and it not easy to lose color or get aged. The light bar has many modes function offer to choose, and we can design according to your demands.no extra cost about the patterns.It can be installed on all kinds of special vehicles.

  Starway DUAL Linner Warning LED Light bar is a 360-degree lighting system with extremely low amps. Using our own low profile design, it provides  superior aerodynamics and greater fuel savings than other light bars. Each light bar contains 22 GEN III TIR modules. In total, there are 264 1 Watt LEDs.
The 48" DUAL Linner LED Light Bar comes with a 15-foot cord and 9 Button Control Box. also we can offer you special switch box with LED indicator , that 's very popular in the current market , all of switches are programmed  ,which shows the light bar flash patterns from inside the vehicle.

  This Warning  led light bar  included are 12 primary warning modules, 6 Traffic Advisor modules, 2 Take Down Lights and 2 Alley Lights. Primary warning lights are working in 16 flash patterns , 6 traffic advisor modules are working in 3 flash patterns ( left to right ,right to left ,middle to both sides) , Takedown and alley can be flashing and steady burn . All of these functions above are controlled by independent switches .

  The Starway Warning LED light bar is very easy to install and comes with mounting hardware for roof mount. There is no need to drill unnecessary holes into your vehicle to install this Light Bar. The dual lightbar can also be hardwired to your existing switch box.  Fully encapsulated and fully waterproof, all LED modules and flasher boards are epoxy coated, keeping it safe from all weather and moisure conditions.
Super think height only 2.35", yes, you don't mistaken the height that 's just 2.35" ,superior thin !!! It will make the light bar become much more streamlined and more brighter and far bright .

2. Features

●   Voltage: 12VDC
●   16 Selectable flash patterns
●    Generation 4 TIR LED technology
●    15' cable and Self contained internal flasher
●    Sleek design with clear lens for stealth look
●    Includes wire harness for easy installation
●    Gutter Brackets included for mounting
●    Colors:Amber, Blue, Red, Red/Blue and More
●    12 LEDs in every module. (264 LEDs total)
●    Fully encapsulated, fully weatherproof .
●    Perfect for police fire EMS and construction vehicle lighting and airforce

3. Specifiation:

Model
LTF-A815AB-2L LED Linear Light bar

Work voltage

DC12V

Type

Traffic Signal

Environment

-40 ℃~ +50 ℃

Lens material

polycarbonate(PC)

Dome material

Aluminum alloy

Bracekt material

Stainless

Installation:

Screws

Light type

LEDS

LED total 264 LEDs
Primary warning modules 12
Traffic Advisor modules 6
Take Down Lights 2
Alley Lights 2

Color

 Amber, Blue, Red, Red/Blue and More

Dimensions

Length: 48" x Width: 11.8" x Height 2.35"


Length: 48" x Width: 11.8" x Height 2.35"
